PVC Suction Hose

Applications
Suitable for conveying powder, grain, water and oil, etc. in the industry, agriculture, irrigation and civil engineering. It is the ideal alternative of rubber hose and metal pipe.

Characteristics
Light, elastic, minus pressure resistant and with good adaptability.

Working Temperature: -5°C-65°C
Specifications Of Pvc Suction Hose



Item No.	Inch	I.D.	O.D	M/Roll	W.P.	B.P.	Weight	CBM/Roll
		MM	MM	M	BAR		KG/Roll	M³
		19	23		8	24	11.5	0.11
SH-19	3/4”	19	24	50	8	24	12.5	0.13
		19	25		9	27	14	0.14
		25	29		8	24	14.5	0.16
SH-25	1”	25	30	50	8	24	16	0.18
		25	31		9	27	17.5	0.2
		32	36		7	21	17.5	0.16
		32	37		7	21	19	0.18
SH-32	1-1/4”	32	38	50	8	24	20	0.19
		32	39		9	27	22.5	0.20
		32	40		9	27	27.5	0.21
		38	42		6	18	22.5	0.18
		38	43		6	18	25	0.18
		38	44		7	21	27.5	0.26
SH-38	1-1/2”	38	45	50	7	21	30	0.28
		38	46		7	21	35	0.29
		38	48		7	21	40	0.31
		50	54		5	15	27.5	0.40
		50	55		5	15	32.5	0.41
		50	56		6	18	35	0.42
SH-50	2”	50	57	50	6	18	40	0.43
		50	58		6	18	46	0.44
		50	59		6	18	50	0.46
		50	60		7	21	55	0.48
		63	69		5	15	44	0.70
		63	70		5	15	47.5	0.71
SH-63	2-1/2”	63	71	50	6	18	58.5	0.72
		63	72		6	18	61.5	0.74
		63	73		6	18	65	0.75
		75	81		4	12	58	1.00
		75	82		4	12	62.5	1.02
		75	83		4	12	72.5	1.04
SH-75	3”	75	84	50	5	15	75	1.05
		75	85		5	15	82.5	1.06
		75	86		5	15	87.5	1.07
		75	87		6	18	92.5	1.08
		100	108		4	12	97.5	2.00
		100	109		4	12	107.5	2.12
		100	110		5	15	115	2.15
SH-100	4	100	111	50	5	15	127.5	2.18
		100	112		5	15	145	2.20
		100	114		6	18	160	2.25
< p>		100	116		6	18	185	2.30
		100	124		7	21	300	3.10
		125	135		4	12	90	3.05
		125	137		4	12	99	3.10
SH-125	5”	125	139	30	4	12	108	3.14
		125	141		5	15	141	3.20
		150	162		4	12	108	3.10
		150	163		4	12	120	3.20
		150	164		4	12	150	3.25
SH-150	6”	150	166	30	4	12	165	3.35
		150	168		5	15	189	3.40
		150	170		5	15	216	3.45
		150	172		5	15	249	3.50
		150	174		5	15	285	3.55
		200	214		4	12	74.34	0.54
SH-200	8”	200	216	11.8	4	12	82.6	0.55
		254	270		4	12	118	0.84
SH-254	10”	254	274	11.8	4	12	129.8	0.87
		254	274		4	12	141.6	0.89
		305	321		4	12	165.2	1.24
SH-305	12”	305	325	11.8	5	15	182.9	1.30
		305	329		5	15	212.4	1.36
		355	375		5	15	224.2	1.58
SH355	14”	355	379	11.8	5	15	236	1.65
		400	416		4	12	212.4	2.04
SH-400	16”	400	420	11.8	5	15	230.1	2.08
