Applications
Being made of tough PVC mixed with Rubber materials and high tensile polyester reinforcement.
This hose has honed surface which is similar as rubber hose surface, it can work under very high working pressure, and light, flexible, durable, anti-erosion, frost resistant, oil resistant and explosion resistant.
For big sizes, can be made 100m per roll, even longer. All color is available.
Characteristics
The hose is widely used in pneumatic tools, pneumatic washing apparatus, engine components, machine service and civil engineering equipments.
Working Temperature: -10°C-80℃
Specifications of PVC and Rubber Mixed Air Hose
| Item No. |
Inch
|
I.D.
|
O.D.
|
M/Roll
|
W.P.
|
B.P.
|
Weight
|
CBM/Roll
|
|
MM
|
BAR
|
KG/Roll
|
M³
|
|||||
| RPMH-006 |
1/4”
|
6.5
|
12
|
100
|
20
|
60
|
11.0
|
0.024
|
| RPMH-007 |
9/32“
|
7.5
|
13
|
100
|
20
|
60
|
12.2
|
0.026
|
| RPMH-008 |
5/16”
|
8.5
|
14
|
100
|
20
|
60
|
13.4
|
0.026
|
| RPMH-010 |
3/8”
|
10
|
16
|
100
|
20
|
60
|
16.9
|
0.041
|
| RPMH-013 |
1/2”
|
13
|
20
|
50
|
20
|
60
|
12.5
|
0.029
|
| RPMH-016 |
5/8”
|
16
|
25
|
50
|
20
|
60
|
20.0
|
0.040
|
| RPMH-019 |
3/4”
|
19
|
28.5
|
50
|
17
|
52
|
24.4
|
0.056
|
| RPMH-025 |
1”
|
25
|
34.5
|
50
|
16
|
48
|
30.6
|
0.094
|
| RPMH-032 |
1-1/4”
|
32
|
44
|
50
|
15
|
46
|
49.4
|
0.166
|
| RPMH-038 |
1-1/2”
|
38
|
50
|
50
|
15
|
45
|
57.2
|
0.271
|
| RPMH-050 |
2”
|
50
|
64
|
50
|
10
|
30
|
86.4
|
0.375
|
|
